If no error appears, attempt to verify printer functionality.After 10-15 seconds, turn the main power switch on.Turn the printer off, using the main power switch located on the back of the printer.If the issue persists following the steps below, generate a CSO for service. If the troubleshooting steps below appear to resolve the issue, attempt to verify printer functionality by printing several internal prints. The steps below are designed to achieve remote resolution of the issue. Contact center agents (troubleshooting to be performed with customer) Follow the steps listed below to determine the actual cause of the problem and fix or replace the necessary parts.

Internal printer hardware that may cause these problems are the HDD, the Power Supply Unit (PSU) or the Main PCA. Indirect causes can include memory, the Boot ROM DIMM or the HP Jetdirect EIO card. The printer has detected a problem with the Hard Disk Drive (HDD), or the Main PCA. Performing service tests, service utilities and service calibrationsĭocument number: BPP90196 Last updated: 05-Sept-2003 Minimum skill level: 2

Parts required (part numbers are subject to change) HP Designjet 5500 Series Printers - TWI: System Error 1F500XXĬontact center agents (troubleshooting to be performed with customer) The owners of this website have no affiliation to Hewlett Packard nor do we TWI Designjet Documents library presented here as a courtesy of
